W3080410 | Ultrasonic cleaning bath (UA10) | stainless steel | 10 litre maximum tank capacity | with heating and drain

Key Features

• 10 litre maximum tank capacity
• Ideal for cleaning laboratory, surgical, dental, optical, industrial and jewellery items and degassing solutions prior to use in HPLC
• Stainless steel tank and coated case allows for easy cleaning and decontamination
• LCD touch screen to control bath function
• Independent degas function
• Automatically saves last-used parameters and recalls them when unit turned on
• Digital timer from 0 - 199 minutes
• Heating range of 20°C - 80°C
• 37 KHz ultrasonic frequency
• Handles to allow the bath to be safely moved
• Non-slip feet and flexible surface contact for lower ultrasonic vibration
• Frequency overload and thermal protection
• Wide range of accessories such as lids, baskets and item holders available (please see below)

Description

The 10L UA10 stainless steel ultrasonic bath is ideal for cleaning laboratory, surgical, dental, optical and industrial items and instruments. The bath is also highly efficient at cleaning jewellery and mechanical and electrical components as well as for degassing solutions prior to use in applications such as HPLC.

The unit uses powerful transducers that emit a 37 KHz ultrasonic frequency to cause cavitation and the creation of microscopic bubbles that scour any items placed in the bath. Instrument control is achieved through an LCD touch screen and the unit automatically saves last-used parameters and recalls them when unit next turned on.

The UA10 incorporates a heating system to enhance the cleaning process and the instrument includes functionality to maintain ultrasonic efficiency at different temperatures. The bath includes safety features to prevent frequency overload or over-heating.

The bath incorporates handles to allow it to be safely moved as well as non-slip feet and flexible surface contact for lower ultrasonic vibration. The bath also features a digital timer and is supplied with a lid and a tray on which to place items prior to loading into the tank.

Optional Accessories

The accessories listed below are suitable for use with 10 litre ultrasonic cleaning baths. Please contact Advance Scientific for pricing.

Part Number	Description
U10010	Stainless steel lid
U10210	Stainless steel trays
U10110	Stainless steel basket
U10410	Positioning lids
5660	Stabilising ring for Erlenmeyer flasks (Type S: Red) | PVC-covered steel | External diameter: 70 mm : Internal diameter: 27 mm | Weight: 0.3 Kg
5661	Stabilising ring for Erlenmeyer flasks (Type M: Yellow) | PVC-covered steel | External diameter: 105 mm : Internal diameter: 52 mm | Weight: 0.5 Kg
5662	Stabilising ring for Erlenmeyer flasks (Type L: Blue) | PVC-covered steel | External diameter: 140 mm : Internal diameter: 76 mm | Weight: 1.2 Kg

Specifications

Manufacturer	Wiggens
Model number	UA10
Tank capacity (maximum)	10 litres
Timer	1 minute to 199 minutes
Ultrasonic frequency	37 KHz
Working power	200 W maximum
Heater power	270 W
Heating range	20°C - 80°C
Construction	Stainless steel
Dimensions (internal: W x D x H)	300 mm x 240 mm x 150 mm
Dimensions (external: W x D x H)	383 mm x 267 mm x 305 mm
Drain	Yes
