100400 | Wiggens overhead stirrer with high speed and torque and TFT digital display (WB3000-D)
- Brushless DC motor for longer instrument lifespan, low maintenance and high efficiency
- Bright TFT screen and intuitive on-touch control
- Fully enclosed & compact casing
- Switchable between low speed/ high torque and high speed/ low torque
- PID feedback ensures constant motor speed even if viscosity changes
- Precise speed adjustment
- Easily adjustable key-less chuck
- RS-232 and USB interfaces to control and monitor instrument parameters and performance
- Wide range of optional impellers available
The Wiggens WB3000-D features a brushless motor that is quieter and lasts considerably longer than standard stirrer motors. It has a bright TFT screen and on-touch control and uses the latest microprocessor technology to generate a stable and accurate stirring process and incorporates internal overload protection to prevent motor damage.
The powerful motor in the WB3000-D, and the ability to switch from low to high torque and low to high speed, makes this instrument ideal for stirring high viscosity fluids. The unit also features PID feedback that ensures a constant motor speed even if viscosity changes during stirring.
RS-232 and USB interfaces are built into the WB3000-D to remotely control and monitor instrument parameters and performance. The stirrer can be used with a wide range of optional impellers.
|Display/ control mode||TFT digital display/ On-touch control|
|Speed accuracy (rpm)||±1|
|Torque (N-cm)||Low: 339 | High: 68|
|Speed range (rpm)||Low: 20 - 600 | High: 601 - 3000|
|Chuck range||10 mm maximum diameter|
|Maximum torque (N-cm)||339|
|Maximum viscosity (cP)||100000|
|Maximum capacity (L H2O)||100|
|Output power (W)||150|
|Dimensions (W x D x H)||95 mm x 200 mm x 230 mm|
