W6061100 | Forced Convection Oven with 100 L capacity and PID temperature control (WF-12G)








Key Features

  • Ideal for drying applications requiring gentle air flow
  • Gravity-flow convection with vertical air flow for uniform sample heating
  • Tempered glass window for safe sample monitoring
  • Stainless steel interior with rounded inner chamber corners for improved airflow and easier cleaning
  • Advanced PID temperature control with auto-tuning and calibration
  • Digital LED display with touch keypad
  • Operating range from ambient plus 10°C - 260°C
  • Timer range from 1 minute - 99 hours:59 minutes
  • Safety features including over-temperature limit protection and door open alarm
  • Two adjustable top slide vents help to control inner air vapour circulation

Description

The WF-12G forced convection oven is ideal for drying applications that require gentle airflow. The instrument features gravity-flow convection with vertical airflow for uniform sample heating. The oven has a stainless steel interior with rounded inner chamber corners for improved airflow and easier cleaning and a tempered glass window for safe sample monitoring.

Instrument monitoring and operation is through an LED display with touch keypad that controls the advanced PID temperature system. The WF-12G has a number of safety features that include over-temperature limit protection and a door open alarm. Two adjustable top slide vents help to control inner air circulation.

Specifications

ManufacturerWiggens
Model numberWF-12G
DisplayLED with touch keypad | 0.1°C resolution
Incubator chamber volume100 L
Temperature rangeAmbient plus 10°C - 260°C
Temperature stability±0.6°C at 100°C
Timer range1 minute - 99 hours:59 minutes | delayed ON/OFF
Number of shelves2 as standard (additional shelves can be added)
Heating power1500 W
Inner dimensions480 mm x 460 mm x 500 mm
Outer dimensions600 mm x 690 mm x 810 mm
Weight63 Kg
Control/ CalibrationPID
